Mechanical engineering and drafting on the Gold Coast
Drafting Central in Burleigh Waters, Queensland, turns sketches, photos and old drawings into drawings and designs you can build from, for customers across Australia and online anywhere.
ABOUT US
We are an Australian owned and operated multi-disciplinary mechanical engineering and consultancy organisation based in South East Queensland.
Our team of professionals have over 35 years of extensive knowledge in Project Management, Material Handling, Plant Design, and new product Research & Development. With a solid skillset and broad perspective, we provide on-time and on-budget delivery of projects, designed for seamless manufacturing processes.
We ensure consistent & positive results, well-developed problem solving solutions and effective people & project management. It is our mission to always provide initiative, diligence and strong attention to detail within our collaborative team, so as to excel in environments where priorities frequently change.
Quality and safety in design is our priority, we meet and exceed the Australian Standards that apply to your products, accompanied with a strong understanding of the requirements you need under the Quality System ISO 9001 and 9002, ensuring exceptional delivery of your designs.
We value our clients and stakeholders – we believe that your success is our success.
From the moment we view your project, we maintain clear communication from concept to completion. By integrating our expertise, we have the ability to streamline projects ensuring increased control, effective & efficient deliverables, and increased cost savings to your business.
HOW IT WORKS
Upload your job
Upload it online or use the quote form. A phone photo is fine.
We confirm and quote
You get a reply by email, usually within one business day.
Check and approve online
Mark up your drawing on screen. Send corrections or approve it.
Download your drawing
Your approved PDF drawing (3D PDF where it is part of the job), kept private to you.
OUR SERVICES
Got a job that needs a finished drawing? Upload it or request a quote below.
MECHANICAL ENGINEERING
Automated Systems, Static Devices, Hydraulic Systems, Low Voltage Control Systems, PLC Controlled Systems, Thermal Fire Warning Control Systems, Safety Guarding Systems
SAFETY IN DESIGN
Meet & Exceed Australian Standards, Product Certification, Finite Elements Analysis (FEA)
RESEARCH & DEVELOPMENT
New Products, Reverse Engineering, Cost Effective Redesigns
DRAWINGS
Workshop Drawings, Product Manuals, 3D Modelling, Sales & Fabrication Drawings
3D SCANNING
Point cloud capture and reverse engineering of existing plant and equipment.
PATIENT APPLICATIONS
Equipment for patients and the people who care for them: clear drawings and design records.
MEDICAL DESIGNS
Surgical Devices, Disabled Services, Prosthetics
MATERIALS HANDLING
Recycling/Refuse Vehicles, Bin Lifting Devices, Material Recovery Facilities, Waste & Recycling Centres, Conveyor Designs, FoGo Systems, Water Trucks & Tailgate Loaders, Scissor Lift Tables, Dock Levellers
TRAFFIC MANAGEMENT SYSTEMS
Design, Build, Install
RAIL CORRIDOR SAFETY
Rail corridor safety equipment: design, drawings and design records for approval.
CONTAINER DEPOSIT SCHEMES
Sorting Systems, Deposit Site Design Layouts, Drive Thru & Self Serve
PROJECT MANAGEMENT
End to End Project Management
RECENT WORK
A selection of drawings and models we’ve produced for clients.
FILES WE ACCEPT AND DELIVER
Send us
Anything you have – a sketch is enough to start.
Photos & sketchesPDFDWGDXFSTEP / STPIGESAutodesk InventorSolid EdgeZIPWe send back
Checked and approved online, then yours to download.
PDF drawings3D PDFQUESTIONS WE GET ASKED
What do I need to send?
A sketch, photo, PDF or CAD file is enough to start. The more you can tell us (dimensions, materials, quantities, what it is for), the quicker and more accurate the quote. Not sure? Send what you have and we will ask.
Which file types can I send?
Photos and phone pictures, PDFs, DWG and DXF, STEP and IGES, Autodesk Inventor, Solid Edge and ZIP files. If yours is not on the list, send it anyway and we will tell you.
Do I need a 2D drawing or a 3D model?
A 2D drawing is what most workshops and fabricators build from. A 3D model helps with design, checking fit and visualising the part. Many jobs need both. Tell us what it is for and we will recommend the right one.
How long will it take?
We reply to every quote request by email, usually within one business day. The time to complete depends on the size of the job, and we confirm it with your quote.
How do I check and approve my drawing?
We put the drawing in your private online portal. You can mark it up on screen, draw, type notes in colour and send corrections back. When you are happy, you approve it and download your approved PDF drawing, including 3D PDFs where they are part of the job.
What if I need a change later?
Corrections before you approve are part of the job. After approval, quick changes that take us under 10 minutes are free; larger changes are charged and we confirm the cost with you before we start. See our Terms and Conditions for how payment works.
Are my files private?
Yes. Your files are stored privately and can only be opened by you and Drafting Central. NDAs are available on request.
Do you work with customers outside Australia?
Yes. We work online with customers anywhere in the world. Send your job or files through the website and we reply by email, usually within one business day (Queensland, Australia time). Quotes and invoices are in Australian dollars, and you can pay by card (Visa, Mastercard or American Express), with PayPal, or by direct deposit into our bank account (no fees).
How much does it cost?
Every job is different, so we quote each one. Send us your job and we will confirm the price before we start.
Get a Quote
Tell us about your job and attach your sketch or CAD files. We work online with customers anywhere in the world, and reply by email, usually within one business day.
Based in
Burleigh Waters, Queensland
Logic will take you from A – Z
Imagination will take you anywhere…
